Image Sensor | 1/27” Progressive Scan CMOS Starlight Sensor |
Lens | Focal Length: 4 mm Aperture: F1.6 Field of View: 105° (Diagonal), 88°(Horizontal), 45°(Vertical) |
Motion Range | Pan Mechanical Range: 326° (360° Pan Coverage) Tilt Mechanical Range: 53° (98° Tilt Coverage) |
Night Vision | 850 nm IR LED Starlight Color Night Vision |
Lighting | 2× Built-in Spotlights |
Interface & Button | 1× Ethernet Port 1× RESET Button 1× MicroSD Card Slot (Up to 512GB) |
Maximum Resolution | 4K 8MP (3840 × 2160 px) |
Frame Rate | 25 fps |
Digital Zoom | 18x |
Video Compression | H.264 |
Live View | Yes |
Image Enhancement | 3DNR WDR |
Audio Input & Output | Built-in Microphone and Speaker |
Audio Communication | Two-Way Audio with Noise Cancellation |
Siren Volume | 99 dB (Level measured at 4-inch/10-cm distance) |
Local Storage | MicroSD Card Slot on Camera (Up to 512 GB) General Information about using MicroSD Cards > |
Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
AI Detection | Motion Detection Person Detection Pet Detection Vehicle Detection |
Activity Zones | Yes |
Output Notification | System Notification System Notification with Snapshot (Tapo Care Services) |
Network Connectivity | Connect via Wi-Fi or Ethernet |
Wireless Connectivity | IEEE 802.11a/b/g/n/ac/ax, 2.4 GHz /5 GHz |
Ethernet Port | Yes |
RTSP | Yes |
ONVIF | Yes |
Security | SSL/TLS,AES |
Power Source | 12V DC Power Adapter |
Input Voltage | 100-240 V, 50/60 Hz |
Output Voltage | 12 V, 1 A (DC Power) |
Smart Integration | Google Assistant, Amazon Alexa |
Weather Resistance | IP66 |
System Requirements | Tapo App: iOS 12.0+ and Android 5.0+ operating systems. |
Mounting Options | Ceiling-Mounted Wall-Mounted Pole-Mounted (Pole-Mounting loops required but not included) |
Operating Temperature | -30~60 |
Storage Temperature | -40~60 |
Operating Humidity | 10%~90% RH, Non-condensing |
Storage Humidity | 0~90% RH, Non-condensing |
Dimensions ( W x D x H ) | 147.4 × 74.7 × 165.4mm(Mounting Bracket Included) 147.4 × 74.7 × 157.4mm(Mounting Bracket Excluded) |
Package Content | Tapo C560WS Camera×1 DC Power Adapter×1 Mounting Template Sticker×1 Mounting Bracket×1 Mounting Anchors and Screws Bracket Screws×2 Waterproof Seal×1 Waterproof Cable Attachments×1 Quick Start Guide |
Certifications | FCC, RoHS, RCM |
